Lilac 1965 Models Brochure, Sides 1 and 2, from 1964, size 30 x 21 cm, scanned at 75 dpi. This is a bit too large to print without resizing or cropping on a US Letter or A4 printer. Thanks to Katsuyuki Inoue for the scans.
This brochure depicts the domestic Japanese model of the 1965 US Marusho ST and shows the differences - painted front fender, low bars, re-positioned mirrors, turnsignals, Lilac badging, etc. The reverse illustrates the V-twin models that Lilac expected to sell, but virtually none of these bikes, developed before Lilac went bankrupt in 1961, were assembled and sold while the 500cc was being produced.
Lilac R-92 Electra-type Brochure, Sides 1 and 2,
from late 1966, size 26 x 13 cm, scanned at 75 dpi.
